iPad mini (7th Generation) with A17 Pro Chip: Specifications and Analysis
The iPad mini (7th generation), also identified as the iPad mini (A17 Pro) or iPad mini (2024), represents the latest evolution of 's highly portable tablet. This iteration marks a significant step forward by integrating the powerful A17 Pro chip, a key upgrade that delivers substantial performance enhancements and unlocks access to advanced features such as Intelligence 1. Alongside this core improvement, the new model boasts increased base storage, enhanced connectivity options, and compatibility with the Pencil Pro 2. Designed for users who prioritize portability without compromising performance, the iPad mini (7th generation) offers a compelling package for a wide range of applications.
iPad mini (7th Generation) - Technical Specifications
Design and Dimensions
| Height |
7.69 inches (195.4 mm) |
| Width |
5.3 inches (134.8 mm) |
| Depth |
0.25 inch (6.3 mm) |
| Weight (Wi-Fi) |
0.65 pound (293 grams) |
| Weight (Wi-Fi + Cellular) |
0.66 pound (297 grams) |
| Colors |
Blue, Purple, Starlight, and Space Gray |
| Enclosure Material |
100% recycled aluminum |
| Magnets |
100% recycled rare earth elements |
Display
| Size |
8.3-inch (diagonal) |
| Type |
Liquid Retina display, LED-backlit, IPS technology |
| Resolution |
2266-by-1488 pixels at 326 ppi |
| Color Gamut |
Wide color (P3) |
| Technology |
True Tone |
| Features |
Fully laminated display, Antireflective coating, Fingerprint-resistant oleophobic coating |
| Brightness |
500 nits (typical maximum) |
| Pencil Support |
Pencil Pro, Pencil (USB-C), Pencil hover |
Chip
| Chip |
A17 Pro chip |
| CPU |
6-core CPU (2 performance cores and 4 efficiency cores) |
| GPU |
-designed 5-core GPU |
| Neural Engine |
16-core Neural Engine |
Storage and RAM
| Storage Options |
128GB |
| RAM |
8GB |
Camera
| Rear Camera |
12MP Wide, ƒ/1.8 aperture, Up to 5x digital zoom |
| Rear Camera Lens |
Five-element lens |
| Rear Camera Flash |
True Tone flash |
| Rear Camera Features |
Autofocus with Focus Pixels, Panorama (up to 63MP), Smart HDR 4, Advanced red-eye correction, Auto image stabilization, Burst mode |
| Front Camera |
12MP Center Stage, ƒ/2.4 aperture |
| Front Camera Features |
Smart HDR 4 |
| Image Formats |
HEIF and JPEG |
Video Recording
| 4K Video Recording |
24 fps, 25 fps, 30 fps, or 60 fps |
| 1080p HD Video Recording |
25 fps, 30 fps, or 60 fps |
| 720p HD Video Recording |
30 fps |
| Slow-motion Video |
1080p at 120 fps or 240 fps |
| Time-lapse Video |
Yes, with stabilization |
| Extended Dynamic Range Video |
Up to 30 fps |
| Cinematic Video Stabilization |
Up to 4K, 1080p, and 720p |
| Other Video Features |
Continuous autofocus video, Playback zoom |
| Video Formats |
HEVC, H.264, AV1, ProRes |
Connectivity
| Wi-Fi |
Wi-Fi 6E (802.11ax), 2x2 MIMO, Simultaneous dual-band (2.4 GHz and 5 GHz) |
| Bluetooth |
Bluetooth 5.3 |
| Cellular (Wi-Fi + Cellular models) |
5G (sub‑6 GHz) with 4x4 MIMO, Gigabit LTE with 4x4 MIMO |
| SIM Card |
eSIM (no physical nano-SIM slot) |
| USB-C Port |
USB 3 (up to 10Gb/s), DisplayPort over USB-C |
Battery and Power
| Battery |
Built-in 19.3-watt-hour rechargeable lithium-polymer battery |
| Battery Life (All Models) |
Up to 10 hours of surfing the web on Wi‑Fi or watching video |
| Battery Life (Wi-Fi + Cellular) |
Up to 9 hours of surfing the web using cellular data |
| Charging |
Via 20W USB-C power adapter (included) or USB-C to computer |
Other Features
| Touch ID |
Integrated into the top button |
| Speakers |
Landscape stereo speakers |
| Microphones |
Dual microphones for calls, video, and audio recording |
| Sensors |
Three-axis gyro, Accelerometer, Barometer, Ambient light sensor |
| Pay |
Supported via Touch ID |
|
Yes |
| Accessibility |
Comprehensive suite of features included |
A17 Pro Chip: Architecture and Performance Analysis
Architecture
| Architecture |
64-bit ARM-based SoC |
| Manufacturing Process |
3-nanometer |
| CPU Cores |
6 (2 Performance - Everest, 4 Efficiency - Sawtooth) |
| Performance Core Clock |
3.78 GHz |
| Efficiency Core Clock |
2.11 GHz |
| GPU Cores |
-designed 5-core GPU |
| GPU Features |
Hardware-accelerated ray tracing, Mesh shading |
| Neural Engine |
16-core, 35 TOPS |
| RAM |
8 GB LPDDR5 |
| Video Decoding |
Hardware decoding of AV1 |
| USB Controller |
USB 3.2 Gen 2 (up to 10 Gb/s) |
| Transistors |
19 billion |
Performance Metrics
asserts that the A17 Pro chip in the iPad mini (7th generation) delivers a 30% faster CPU performance and a 25% faster GPU performance compared to the A15 Bionic found in the previous model.
| Geekbench 6 (Single-Core - Average) |
~2940 |
| Geekbench 6 (Multi-Core - Average) |
~7299 |
| AnTuTu 10 (Total Score - Reported) |
Exceeds 1.5 million |
| Neural Engine Performance |
35 TOPS (Trillions of Operations Per Second) |
| Gaming Capabilities |
Console-quality gaming (e.g., Resident Evil, Death Stranding) |
Table 1: A17 Pro vs. A15 Bionic - Key Specifications
| Specification |
A17 Pro |
A15 Bionic |
| CPU Cores |
6 (2 Performance, 4 Efficiency) |
6 (2 Performance, 4 Efficiency) |
| Performance Core Clock |
3.78 GHz |
~2.93 GHz |
| Efficiency Core Clock |
2.11 GHz |
~1.82 GHz |
| GPU Cores |
5 |
5 |
| Neural Engine |
16-core, 35 TOPS |
16-core, 15.8 TOPS |
| RAM |
8 GB LPDDR5 |
4-6 GB LPDDR4X |
| Manufacturing Process |
3 nm TSMC N3 |
5 nm TSMC N5P |
Feature Enhancements and Intelligence
A primary highlight of the iPad mini (7th generation), made possible by the A17 Pro chip, is the integration of Intelligence 1. This suite of intelligent features leverages the power of silicon and generative models to enhance user interaction with language and images 6. Intelligence enables capabilities such as understanding and creating language, generating custom emojis (), taking actions across apps, and utilizing personal context to streamline everyday tasks 2. It is important to note that some Intelligence features may be in beta or have certain limitations upon initial release 8. The new iPad mini also boasts full compatibility with the Pencil Pro, unlocking a range of enhanced functionalities 1. These features include squeeze gestures for quick tool switching, barrel roll for precise control of certain tools, haptic feedback for a more tactile drawing and writing experience, and Find My support, allowing users to locate a misplaced Pencil 3. The combination of the powerful A17 Pro chip and these intelligent features positions the iPad mini 7 as a versatile tool for both productivity and creativity.
Comparative Analysis: iPad mini 7 vs. iPad mini 6
The upgrade from the iPad mini 6 to the 7 represents a significant internal overhaul while maintaining the familiar and well-regarded design. The most prominent improvement is the shift from the A15 Bionic chip to the considerably more powerful A17 Pro 3. This new chip brings substantial gains in CPU and GPU performance, as well as a more than doubled Neural Engine capability 3. The iPad mini 7 also benefits from a doubling of the base RAM, increasing it from 4GB to 8GB, and a doubling of the base storage, moving from 64GB to 128GB 1. Connectivity has also been enhanced with the inclusion of Wi-Fi 6E, Bluetooth 5.3, and an upgraded USB-C port that now supports USB 3 speeds 2. The camera system sees minor improvements with the adoption of Smart HDR 4 and an updated True Tone flash 2. In contrast, the design, display size and resolution, and battery capacity remain largely the same 1. A key differentiator for the iPad mini 7 is the support for Intelligence and the Pencil Pro, features not available on the previous generation 1. This evolutionary update prioritizes performance and new software capabilities, offering a noticeable upgrade for users seeking enhanced power and features in a compact form factor.
Table 2: iPad mini 7 vs. iPad mini 6 - Specification Comparison
| Specification |
iPad mini 7 (A17 Pro) |
iPad mini 6 (A15 Bionic) |
| Processor |
A17 Pro |
A15 Bionic |
| RAM |
8 GB |
4 GB |
| Base Storage |
128 GB |
64 GB |
| Wi-Fi Standard |
Wi-Fi 6E |
Wi-Fi 6 |
| Bluetooth Version |
5.3 |
5.0 |
| USB-C Standard |
USB 3 (up to 10Gb/s) |
USB 2 |
| Front Camera Features |
Smart HDR 4 |
Smart HDR 3 |
| Pencil Support |
Pro & (USB-C) |
2nd gen & (USB-C) |
Conclusion
The iPad mini (7th generation) with the A17 Pro chip represents a compelling upgrade for users seeking a powerful yet highly portable tablet. The integration of the A17 Pro chip delivers substantial performance improvements, enabling demanding tasks and unlocking new features like Intelligence. The doubling of the base storage and the increase in RAM address key user needs, contributing to a smoother and more efficient experience. Enhanced connectivity options, including Wi-Fi 6E and USB 3, further improve the device's versatility. While the design remains consistent with its predecessor, the internal enhancements and the addition of Pencil Pro support make the iPad mini 7 a significant step forward. By maintaining the same starting price despite these upgrades, has presented a strong value proposition in the compact tablet market, making the iPad mini (7th generation) an attractive option for a wide range of users.
